Dahua DSM-C01 720p HDCVI DSM Camera
This is a placeholder price. Please contact us for a quote.
Most orders ship within 30 working days. Stock status shown on this page is not real-time.
After you place your order, please check the order confirmation email from our team. We will confirm stock, lead time and shipping before dispatch. If an item is out of stock, we may propose a compatible replacement model for your approval.
Working to a project deadline? Contact us before ordering.
Our team can confirm specifications, stock and pricing before you order.
Email sales@icctvzone.com or contact us.
Couldn't load pickup availability
Need help choosing the right model? I can confirm specifications, stock and lead time before you order.
DSM-C01
DSM Camera
> CMOS sensor; imaging of high quality.
> Eyes can be recognized when it's under totally dark condition or humans wear sunglasses (not block IR light) with IR fill light.
> Special IR auxiliary illumination design to protect eyes.
Product Data
| Technical Specification | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Sensor | 1/3 inch CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Effective Pixels | 1280 (H) × 720 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Electronic Shutter Speed | PAL: 1/25s–1/100000s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Frame Rate | 50Hz: 1280 × 720@25fps, 1280 × 720@50fps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Focal Length | 6 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Gain Control | Auto | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| White Balance | Auto | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| HLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Digital WDR | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 2D NR | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 3D NR | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Field of View | Horizontal: 82°; vertical: 46° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Iris | Fixed | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Image Mirror | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Anti-flicking | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Fill Light | 940 nm IR auxiliary illumination | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Video Output Standard | HDCVI | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power Supply | 9V–16V DC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power Consumption | 4.2W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Operating Temperature | -30°C to +70°C (-22°F to +158°F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Operating Humidity | <95% (non-condensation) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Camera Dimensions (L × W × H) | 82 mm × 45 mm × 5mm (3.23'' × 1.77'' × 0.20'') | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Net Weight | 221 g (0.49 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Order & Pricing Information for Surveillance Products
Please note the following important details when ordering surveillance products from ICCTVZONE:
- Order confirmation: After you place an order, please check the confirmation email from our team. We will confirm stock, lead time and shipping before dispatch.
- Stock & replacements: Inventory status is not real-time. If an item is out of stock, we may propose a compatible replacement model for your approval.
- Final pricing: Prices shown are indicative. The final price is confirmed on the Proforma Invoice (PI) after order confirmation.
- Project-specific pricing: Some products are configured for project requirements; pricing may vary with quantity and specification.
- Minimum order: A minimum order value may apply to non-stock or project items; our team will confirm before processing.
- Shipping costs: Shipping is calculated separately and added to the order total.
- Duties & taxes: Import duties, taxes and customs clearance fees are not included in the product price or shipping quote. These charges are the customer's responsibility.
- Genuine products: We supply genuine products from leading brands with current firmware.
- Technical support: Our engineers provide pre-sales and after-sales technical support.
- Warranty: Warranty terms depend on the product and order type; we will confirm the applicable coverage in writing.
Questions? Contact sales@icctvzone.com.
Product Features
What this model is for, what it does well, and what to confirm before it goes on a project.
Driver-facing in-cab monitoring where a compact 720p HDCVI camera with discreet 940 nm IR fill light is needed.
A slim 82 x 45 x 5 mm body and 221 g weight make it easy to mount in tight vehicle interiors.
The 940 nm IR fill light supports eye recognition in darkness or when sunglasses do not block IR light.
Rated from -30°C to +70°C with under 95% non-condensing humidity for demanding cabin conditions.
